Ball Bearing Size Chart for Engineers, Buyers, Distributors & Repair Shops

Ball bearings come in different types and sizes. Here, we will provide detailed ball bearing size charts, including bearing model number, bore diameter, outside diameter, bearing width, load rating, and other key data.

You can use these charts to check the bearing size by model number, or find the correct bearing number based on the required dimensions.

Please note: before purchasing bearings, always confirm the actual size, tolerance, clearance, sealing type, and application requirements with the manufacturer. The size chart only lists common ball bearing dimensions and is for reference only.

BKZ Industry is a bearing manufacturer in China with two factories. We can produce and supply almost all types of ball bearings you need. If you need to purchase ball bearings in bulk, contact BKZ Industry by submitting the form or send email to sales@bkzindustry.com with your bearing number, size, drawing, quantity, or application details.

Now, let’s check the detailed ball bearing size charts.

Tip: The chart is very long. You can press Ctrl + F on Windows or Command + F on Mac, then enter the bearing number, size, or any other information you have to find the bearing size you need quickly.

ball bearings

Deep Groove Ball Bearing Size Chart

Bearing Model Bore Diameter (mm) Outside Diameter (mm) Bearing Width (mm) Basic Dynamic Load Rating (kN) Basic Static Load Rating (kN) Grease Limiting Speed (r/min) Oil Limiting Speed (r/min) Approximate Mass (kg)
619/3 3 8 3 0.45 0.15 38000 48000 0.0008
623 3 10 4 0.65 0.22 38000 48000 0.002
628/4 4 9 3.5 0.55 0.18 38000 48000 0.0008
619/4 4 11 4 0.95 0.35 36000 45000 0.002
624 4 13 5 1.15 0.4 36000 45000 0.0003
634 4 16 5 1.88 0.68 32000 40000 0.005
619/5 5 13 4 1.08 0.42 34000 43000 0.0025
605 5 14 5 1.05 0.5 30000 38000 0.0045
625 5 16 5 1.88 0.68 32000 40000 0.004
635 5 19 6 2.8 1.02 28000 36000 0.008
628/6 6 13 5 1.08 0.42 34000 43000 0.0021
619/6 6 15 5 1.48 0.6 32000 40000 0.0045
606 6 17 6 1.95 0.72 30000 38000 0.006
626 6 19 6 2.8 1.05 28000 36000 0.008
628/7 7 14 5 1.18 0.5 32000 40000 0.0024
619/7 7 17 5 2.02 0.8 30000 38000 0.0057
607 7 19 6 2.88 1.08 28000 36000 0.007
627 7 22 7 3.28 1.35 26000 34000 0.014
628/8 8 16 5 1.32 0.65 30000 38000 0.004
619/8 8 19 6 2.25 0.92 28000 36000 0.0085
608 8 22 7 2.32 1.38 26000 34000 0.015
628 8 24 8 3.35 1.4 24000 32000 0.016
628/9 9 17 5 1.6 0.72 28000 36000 0.0042
619/9 9 20 6 2.48 1.08 27000 34000 0.0092
609 9 24 7 3.35 1.4 22000 30000 0.016
629 9 26 8 4.45 1.95 22000 30000 0.019
61800 10 19 5 1.8 0.93 28000 36000 0.005
61900 10 22 6 2.7 1.3 25000 32000 0.011
6000 10 26 8 4.58 1.98 22000 30000 0.019
6200 10 30 9 5.1 2.38 20000 26000 0.032
6300 10 35 11 7.65 3.48 18000 24000 0.053
61801 12 21 5 1.9 1 24000 32000 0.007
61901 12 24 6 2.9 1.5 22000 28000 0.013
16001 12 28 7 5.1 2.4 20000 26000 0.019
6001 12 28 8 5.1 2.38 20000 26000 0.022
6201 12 32 10 6.82 3.05 19000 24000 0.035
6301 12 37 12 9.72 5.08 17000 22000 0.057
61802 15 24 5 2.1 1.3 22000 30000 0.008
61902 15 28 7 4.3 2.3 20000 26000 0.018
16002 15 32 8 5.6 2.8 19000 24000 0.025
6002 15 32 9 5.58 2.85 19000 24000 0.031
6202 15 35 11 7.65 3.72 18000 22000 0.045
6302 15 42 13 11.5 5.42 16000 20000 0.08
61803 17 26 5 2.2 1.5 20000 28000 0.008
61903 17 30 7 4.6 2.6 19000 24000 0.02
16003 17 35 8 6 3.3 18000 22000 0.027
6003 17 35 10 6 3.25 17000 21000 0.04
6203 17 40 12 9.58 4.78 16000 20000 0.064
6303 17 47 14 13.5 6.58 15000 18000 0.109
6403 17 62 17 22.7 10.8 11000 15000 0.268
61804 20 32 7 3.5 2.2 18000 24000 0.02
61904 20 37 9 6.4 3.7 17000 22000 0.04
16004 20 42 8 7.9 4.5 16000 19000 0.05
6004 20 42 12 9.38 5.02 16000 19000 0.068
6204 20 47 14 12.8 6.65 14000 18000 0.103
6304 20 52 15 15.8 7.88 13000 16000 0.142
6404 20 72 19 31 15.2 9500 13000 0.4
61805 25 37 7 4.3 2.9 16000 20000 0.022
61905 25 42 9 7 4.5 14000 18000 0.05
16005 25 47 8 8.8 5.6 13000 17000 0.06
6005 25 47 12 10 5.85 13000 17000 0.078
6205 25 52 15 14 7.88 12000 15000 0.127
6305 25 62 17 22.2 11.5 10000 14000 0.219
6405 25 80 21 38.2 19.2 8500 11000 0.529
61806 30 42 7 4.7 3.6 13000 17000 0.026
61906 30 47 9 7.2 5 12000 16000 0.06
16006 30 55 9 11.2 7.4 11000 14000 0.085
6006 30 55 13 13.2 8.3 11000 14000 0.11
6206 30 62 16 19.5 11.5 9500 13000 0.2
6306 30 72 19 27 15.2 9000 11000 0.349
6406 30 90 23 47.5 24.5 8000 10000 0.71
61807 35 47 7 4.9 4 11000 15000 0.03
61907 35 55 10 9.5 6.8 10000 13000 0.086
16007 35 62 9 12.2 8.8 9500 12000 0.1
6007 35 62 14 16.2 10.5 9500 12000 0.148
6207 35 72 17 25.5 15.2 8500 11000 0.288
6307 35 80 21 33.4 19.2 8000 9500 0.455
6407 35 100 25 56.8 29.5 6700 8500 0.926
61808 40 52 7 5.1 4.4 10000 13000 0.034
61908 40 62 12 13.7 9.9 9500 12000 0.11
16008 40 68 9 12.6 9.6 9000 11000 0.13
6008 40 68 15 17 11.8 9000 11000 0.185
6208 40 80 18 29.5 18 8000 10000 0.368
6308 40 90 23 40.8 24 7000 8500 0.639
6408 40 110 27 65.5 37.5 6300 8000 1.221
61809 45 58 7 6.4 5.6 9000 12000 0.04
61909 45 68 12 14.1 10.9 8500 11000 0.14
16009 45 75 10 15.6 12.2 8000 10000 0.17
6009 45 75 16 21 14.8 8000 10000 0.23
6209 45 85 19 31.5 20.5 7000 9000 0.416
6309 45 100 25 52.8 31.8 6300 7500 0.837
6409 45 120 29 77.5 45.5 5600 7000 1.52
61810 50 65 7 6.6 6.1 8500 10000 0.057
61910 50 72 12 14.5 11.7 8000 9500 0.14
16010 50 80 10 16.1 13.1 8000 9500 0.18
6010 50 80 16 22 16.2 7000 9000 0.258
6210 50 90 20 35 23.2 6700 8500 0.463
6310 50 110 27 61.8 38 6000 7000 1.082
6410 50 130 31 92.2 55.2 5300 6300 1.855
61811 55 72 9 9.1 8.4 8000 9500 0.083
61911 55 80 13 15.9 13.2 7500 9000 0.19
16011 55 90 11 19.4 16.2 7000 8500 0.26
6011 55 90 18 30.2 21.8 7000 8500 0.362
6211 55 100 21 43.2 29.2 6000 7500 0.603
6311 55 120 29 71.5 44.8 5600 6700 1.367
6411 55 140 33 100 62.5 4800 6000 2.316
61812 60 78 10 9.1 8.7 7000 8500 0.11
61912 60 85 13 16.4 14.2 6700 8000 0.23
16012 60 95 11 19.9 17.5 6300 7500 0.28
6012 60 95 18 31.5 24.2 6300 7500 0.385
6212 60 110 22 47.8 32.8 5600 7000 0.789
6312 60 130 31 81.8 51.8 5000 6000 1.71
6412 60 150 35 109 70 4500 5600 2.811
61813 65 85 10 11.9 11.5 6700 8000 0.13
61913 65 90 13 17.4 16 6300 7500 0.22
16013 65 100 11 20.5 18.6 6000 7000 0.3
6013 65 100 18 32 24.8 6000 7000 0.41
6213 65 120 23 57.2 40 5000 6300 0.99
6313 65 140 33 93.8 60.5 4500 5300 2.1
6413 65 160 37 118 78.5 4300 5300 3.342
61814 70 90 10 12.1 11.9 6300 7500 0.114
61914 70 100 16 23.7 21.1 6000 7000 0.35
16014 70 110 13 27.9 25 5600 6700 0.43
6014 70 110 20 38.5 30.5 5600 6700 0.575
6214 70 125 24 60.8 45 4800 6000 1.084
6314 70 150 35 105 68 4300 5000 2.55
6414 70 180 42 140 99.5 3800 4500 4.896
61815 75 95 10 12.5 12.8 6000 7000 0.15
61915 75 105 16 24.3 22.5 5600 6700 0.42
16015 75 115 13 28.7 26.8 5300 6300 0.46
6015 75 115 20 40.2 33.2 5300 6300 0.603
6215 75 130 25 66 49.5 4500 5600 1.171
6315 75 160 37 113 76.8 4000 4800 3.05
6415 75 190 45 154 115 3600 4300 5.739
61816 80 100 10 12.7 13.3 5600 6700 0.16
61916 80 110 16 24.9 23.9 5300 6300 0.44
16016 80 125 14 33.1 31.4 5000 6000 0.6
6016 80 125 22 47.5 39.8 5000 6000 0.821
6216 80 140 26 71.5 54.2 4300 5300 1.448
6316 80 170 39 123 86.5 3800 4500 3.61
6416 80 200 48 163 125 3400 4000 6.74
61817 85 110 13 19.2 19.8 5000 6300 0.285
61917 85 120 18 31.9 29.7 4800 6000 0.62
16017 85 130 14 34 33.3 4500 5600 0.63
6017 85 130 22 50.8 42.8 4500 5600 0.848
6217 85 150 28 83.2 63.8 4000 5000 1.803
6317 85 180 41 132 96.5 3600 4300 4.284
6417 85 210 52 175 138 3200 3800 7.933
61818 90 115 13 19.5 20.5 4800 6000 0.28
61918 90 125 18 32.8 31.5 4500 5600 0.65
16018 90 140 16 41.5 39.3 4300 5300 0.85
6018 90 140 24 50.8 49.8 4300 5300 1.1
6218 90 160 30 95.8 71.5 3800 4800 2.17
6318 90 190 43 145 108 3400 4000 4.97
6418 90 225 54 192 158 2800 3600 9.56
61819 95 120 13 19.8 21.3 4500 5600 0.3
61919 95 130 18 33.7 33.3 4300 5300 0.56
16019 95 145 16 42.7 41.9 4000 5000 0.89
6019 95 145 24 57.8 50 4000 5000 1.15
6219 95 170 32 110 82.8 3600 4500 2.62
6319 95 200 45 157 122 3200 3800 5.74
61820 100 125 13 20.1 22 4300 5300 0.31
61920 100 140 20 42.7 41.9 4000 5000 0.92
16020 100 150 16 43.8 44.3 3800 4800 0.91
6020 100 150 24 64.5 56.2 3800 4800 1.18
6220 100 180 34 122 92.8 3400 4300 3.19
6320 100 215 47 173 140 2800 3600 7.07
6420 100 250 58 223 195 2400 3200 12.9
61821 105 130 13 20.3 22.7 4000 5000 0.34
61921 105 145 20 43.9 44.3 3800 4800 0.96
16021 105 160 18 51.8 50.6 3600 4500 1.2
6021 105 160 26 71.8 63.2 3600 4500 1.52
6221 105 190 36 133 105 3200 4000 3.78
6321 105 225 49 184 153 2600 3200 8.05
61822 110 140 16 28.1 30.7 3800 5000 0.6
61922 110 150 20 43.6 44.4 3600 4500 1
16022 110 170 19 57.4 50.7 3400 4300 1.42
6022 110 170 28 81.8 72.8 3400 4300 1.89
6222 110 200 38 144 117 3000 3800 4.42
6322 110 240 50 205 178 2400 3000 9.53
6422 110 280 65 225 238 2000 2800 18.34
61824 120 150 16 28.9 32.9 3400 4300 0.65
61924 120 165 22 55 56.9 3200 4000 1.4
16024 120 180 19 58.8 60.4 3000 3800 1.8
6024 120 180 28 87.5 79.2 3000 3800 1.99
6224 120 215 40 155 131 2600 3400 5.3
6324 120 260 55 228 208 2200 2800 12.2
61826 130 165 18 37.9 42.9 3200 4000 0.736
61926 130 180 24 65.1 67.2 3000 3800 1.8
16026 130 200 22 79.7 79.2 2800 3600 2.63
6026 130 200 33 105 96.8 2800 3600 3.08
6226 130 230 40 165 148 2400 3200 6.12
6326 130 280 58 253 242 2000 2600 14.77
61828 140 175 18 38.2 44.3 3000 3800 0.784
61928 140 190 24 66.6 71.2 2800 3600 1.9
16028 140 210 22 82.1 85 2400 3200 3.08
6028 140 210 33 116 108 2400 3200 3.17
6228 140 250 42 179 167 2000 2800 7.77
6328 140 300 62 275 272 1900 2400 18.33
61830 150 190 20 49.1 57.1 2800 3400 1.114
61930 150 210 28 84.7 90.2 2600 3200 2.454
16030 150 225 24 91.9 98.5 2200 3000 3.58
6030 150 225 35 132 125 2200 3000 3.94
6230 150 270 45 203 199 1900 2600 9.779
6330 150 320 65 288 295 1700 2200 21.87
61832 160 200 20 49.6 59.1 2600 3200 1.25
61932 160 220 28 86.9 95.5 2400 3000 2.589
16032 160 240 25 98.7 107 2000 2800 4.32
6032 160 240 38 145 138 2000 2800 4.83
6232 160 290 48 215 218 1800 2400 12.22
6332 160 340 68 313 340 1600 2000 26.43
61834 170 215 22 61.5 73.3 2200 3000 1.81
61934 170 230 28 88.8 100 2000 2800 3.4
16034 170 260 28 118 130 1900 2600 5.77
6034 170 260 42 170 170 1900 2600 6.5
6234 170 310 52 245 260 1700 2200 15.241
6334 170 360 72 335 378 1500 1900 31.43
61836 180 225 22 62.3 75.9 2000 2800 2
61936 180 250 33 118 133 1900 2600 4.8
16036 180 280 31 144 157 1800 2400 7.6
6036 180 280 46 188 198 1800 2400 8.51
6236 180 320 52 262 285 1600 2000 15.518
61838 190 240 24 75.1 91.6 1900 2600 2.38
61938 190 260 33 117 133 1800 2400 5.25
16038 190 290 31 149 168 1700 2200 7.89
6038 190 290 46 188 200 1700 2200 8.865
6238 190 340 55 285 322 1500 1900 18.691
61840 200 250 24 74.2 91.2 1800 2400 8.28
61940 200 280 38 149 168 1700 2200 7.4
16040 200 310 34 167 191 1800 2000 10.1
6040 200 310 51 205 225 1600 2000 11.64
6240 200 360 58 288 332 1400 1800 22.577
61844 220 270 24 76.4 97.8 1700 2200 3
61944 220 300 38 152 178 1600 2000 7.6
16044 220 340 37 181 216 1400 1800 11.5
6044 220 340 56 252 268 1400 1800 18
6244 220 400 65 355 365 1200 1600 36.5
61848 240 300 28 83.5 108 1500 1900 4.5
61948 240 320 38 142 178 1400 1800 8.2
16048 240 360 37 172 210 1200 1600 14.5
6048 240 360 56 270 292 1200 1600 20
6248 240 440 72 358 467 1000 1400 53.9
61852 260 320 28 95 128 1300 1700 4.85
61952 260 360 46 210 268 1200 1600 13.7
16052 260 400 44 235 310 1100 1500 22.5
6052 260 400 65 292 372 1100 1500 28.8
61856 280 350 33 135 178 1100 1500 7.4
61956 280 380 46 210 268 1000 1400 15
6056 280 420 65 305 408 950 1300 32.1
61860 300 380 38 162 222 1000 1400 11
61960 300 420 56 270 370 950 1300 21.1
61864 320 400 38 168 235 950 1300 11.8
61964 320 440 56 275 392 900 1200 23
6064 320 480 74 345 510 850 1100 48.4
61968 340 460 56 292 418 850 1100 27
6072 360 540 82 400 622 750 950 68
61876 380 480 46 235 348 800 1000 20.5
6080 400 600 90 512 868 630 800 89.4
61892 460 580 56 322 538 600 750 36.28
619/500 500 670 78 445 808 500 630 79.5
60/500 500 720 100 625 1178 450 560 117

Shielded Deep Groove Ball Bearing Size Chart

Z Type Bearing Model 2Z Type Bearing Model Bore Diameter (mm) Outside Diameter (mm) Bearing Width (mm) Basic Dynamic Load Rating (kN) Basic Static Load Rating (kN) Grease Limiting Speed (r/min) Oil Limiting Speed (r/min) Approximate Mass (kg)
619/3-Z 619/3-2Z 3 8 3 0.45 0.15 38000 48000 0.0008
623-Z 623-2Z 3 10 4 0.65 0.22 38000 48000 0.002
628/4-Z 628/4-2Z 4 9 3.5 0.55 0.18 38000 48000 0.0008
619/4-Z 619/4-2Z 4 11 4 0.95 0.35 36000 45000 0.002
624-Z 624-2Z 4 13 5 1.15 0.4 36000 45000 0.0003
634-Z 634-2Z 4 16 5 1.88 0.68 32000 40000 0.005
619/5-Z 619/5-2Z 5 13 4 1.08 0.42 34000 43000 0.0025
605-Z 605-2Z 5 14 5 1.05 0.5 30000 38000 0.0045
625-Z 625-2Z 5 16 5 1.88 0.68 32000 40000 0.004
635-Z 635-2Z 5 19 6 2.8 1.02 28000 36000 0.008
628/6-Z 628/6-2Z 6 13 5 1.08 0.42 34000 43000 0.0021
619/6-Z 619/6-2Z 6 15 5 1.48 0.6 32000 40000 0.0045
606-Z 606-2Z 6 17 6 1.95 0.72 30000 38000 0.006
626-Z 626-2Z 6 19 6 2.8 1.05 28000 36000 0.008
628/7-Z 628/7-2Z 7 14 5 1.18 0.5 32000 40000 0.0024
619/7-Z 619/7-2Z 7 17 5 2.02 0.8 30000 38000 0.0057
607-Z 607-2Z 7 19 6 2.88 1.08 28000 36000 0.007
627-Z 627-2Z 7 22 7 3.28 1.35 26000 34000 0.014
628/8-Z 628/8-2Z 8 16 5 1.32 0.65 30000 38000 0.004
619/8-Z 619/8-2Z 8 19 6 2.25 0.92 28000 36000 0.0085
608-Z 608-2Z 8 22 7 2.32 1.38 26000 34000 0.015
628-Z 628-2Z 8 24 8 3.35 1.4 24000 32000 0.016
628/9-Z 628/9-2Z 9 17 5 1.6 0.72 28000 36000 0.0042
619/9-Z 619/9-2Z 9 20 6 2.48 1.08 27000 34000 0.0092
609-Z 609-2Z 9 24 7 3.35 1.4 22000 30000 0.016
629-Z 629-2Z 9 26 8 4.45 1.95 22000 30000 0.019
61800-Z 61800-2Z 10 19 5 1.8 0.93 28000 36000 0.005
62800-Z 62800-2Z 10 19 6 1.6 0.75 26000 34000 0.0063
61900-Z 61900-2Z 10 22 6 2.7 1.3 25000 32000 0.011
62900-Z 62900-2Z 10 22 8 2.7 1.3 25000 32000 0.008
6000-Z 6000-2Z 10 26 8 4.58 1.98 22000 30000 0.015
6200-Z 6200-2Z 10 30 9 5.1 2.38 20000 26000 0.03
6300-Z 6300-2Z 10 35 11 7.65 3.48 18000 24000 0.05
61801-Z 61801-2Z 12 21 5 1.9 1 24000 32000 0.005
61901-Z 61901-2Z 12 24 6 2.9 1.5 22000 28000 0.008
6001-Z 6001-2Z 12 28 8 5.1 2.38 20000 26000 0.022
6201-Z 6201-2Z 12 32 10 6.82 3.05 19000 24000 0.04
6301-Z 6301-2Z 12 37 12 9.72 5.08 17000 22000 0.06
61802-Z 61802-2Z 15 24 5 2.1 1.3 22000 30000 0.005
61902-Z 61902-2Z 15 28 7 4.3 2.3 20000 26000 0.012
6002-Z 6002-2Z 15 32 9 5.58 2.85 19000 24000 0.03
6202-Z 6202-2Z 15 35 11 7.65 3.72 18000 22000 0.04
6302-Z 6302-2Z 15 42 13 11.5 5.42 16000 20000 0.08
61803-Z 61803-2Z 17 26 5 2.2 1.5 20000 28000 0.007
61903-Z 61903-2Z 17 30 7 4.6 2.6 19000 24000 0.014
6003-Z 6003-2Z 17 35 10 6 3.25 17000 21000 0.04
6203-Z 6203-2Z 17 40 12 9.58 4.78 16000 20000 0.06
6303-Z 6303-2Z 17 47 14 13.5 6.58 15000 18000 0.11
61804-Z 61804-2Z 20 32 7 3.5 2.2 18000 24000 0.015
61904-Z 61904-2Z 20 37 9 6.4 3.7 17000 22000 0.031
6004-Z 6004-2Z 20 42 12 9.38 5.02 16000 19000 0.07
6204-Z 6204-2Z 20 47 14 12.8 6.65 14000 18000 0.1
6304-Z 6304-2Z 20 52 15 15.8 7.88 13000 16000 0.14
61805-Z 61805-2Z 25 37 7 4.3 2.9 16000 20000 0.017
61905-Z 61905-2Z 25 42 9 7 4.5 14000 18000 0.038
6005-Z 6005-2Z 25 47 12 10 5.85 13000 17000 0.08
6205-Z 6205-2Z 25 52 15 14 7.88 12000 15000 0.12
6305-Z 6305-2Z 25 62 17 22.2 11.5 10000 14000 0.22
61806-Z 61806-2Z 30 42 7 4.7 3.6 13000 17000 0.019
61906-Z 61906-2Z 30 47 9 7.2 5 12000 16000 0.043
6006-Z 6006-2Z 30 55 13 13.2 8.3 11000 14000 0.12
6206-Z 6206-2Z 30 62 16 19.5 11.5 9500 13000 0.19
6306-Z 6306-2Z 30 72 19 27 15.2 9000 11000 0.35
61807-Z 61807-2Z 35 47 7 4.9 4 11000 15000 0.023
61907-Z 61907-2Z 35 55 10 9.5 6.8 10000 13000 0.078
6007-Z 6007-2Z 35 62 14 16.2 10.5 9500 12000 0.16
6207-Z 6207-2Z 35 72 17 25.5 15.2 8500 11000 0.27
6307-Z 6307-2Z 35 80 21 33.4 19.2 8000 9500 0.42
61808-Z 61808-2Z 40 52 7 5.1 4.4 10000 13000 0.026
61908-Z 61908-2Z 40 62 12 13.7 9.9 9500 12000 0.103
6008-Z 6008-2Z 40 68 15 17 11.8 9000 11000 0.19
6208-Z 6208-2Z 40 80 18 29.5 18 8000 10000 0.37
6308-Z 6308-2Z 40 90 23 40.8 24 7000 8500 0.63
61809-Z 61809-2Z 45 58 7 6.4 5.6 9000 12000 0.03
61909-Z 61909-2Z 45 68 12 14.1 10.9 8500 11000 0.123
6009-Z 6009-2Z 45 75 16 21 14.8 8000 10000 0.23
6209-Z 6209-2Z 45 85 19 31.5 20.5 7000 9000 0.42
6309-Z 6309-2Z 45 100 25 52.8 31.8 6300 7500 0.83
61810-Z 61810-2Z 50 65 7 6.6 6.1 8500 10000 0.043
61910-Z 61910-2Z 50 72 12 14.5 11.7 8000 9500 0.122
6010-Z 6010-2Z 50 80 16 22 16.2 7000 9000 0.28
6210-Z 6210-2Z 50 90 20 35 23.2 6700 8500 0.47
6310-Z 6310-2Z 50 110 27 61.8 38 6000 7000 1.08
61811-Z 61811-2Z 55 72 9 9.1 8.4 8000 9500 0.07
61911-Z 61911-2Z 55 80 13 15.9 13.2 7500 9000 0.17
6011-Z 6011-2Z 55 90 18 30.2 21.8 7000 8500 0.38
6211-Z 6211-2Z 55 100 21 43.2 29.2 6000 7500 0.58
6311-Z 6311-2Z 55 120 29 71.5 44.8 5600 6700 1.37
61812-Z 61812-2Z 60 78 10 9.1 8.7 7000 8500 0.093
61912-Z 61912-2Z 60 85 13 16.4 14.2 6700 8000 0.181
6012-Z 6012-2Z 60 95 18 31.5 24.2 6300 7500 0.39
6212-Z 6212-2Z 60 110 22 47.8 32.8 5600 7000 0.77
6312-Z 6312-2Z 60 130 31 81.8 51.8 5000 6000 1.71
61813-Z 61813-2Z 65 85 10 11.9 11.5 6700 8000 0.13
61913-Z 61913-2Z 65 90 13 17.4 16 6300 7500 0.196
6013-Z 6013-2Z 65 100 18 32 24.8 6000 7000 0.42
6213-Z 6213-2Z 65 120 23 57.2 40 5000 6300 0.98
6313-Z 6313-2Z 65 140 33 93.8 60.5 4500 5300 2.09
61814-Z 61814-2Z 70 90 10 12.1 11.9 6300 7500 0.138
61914-Z 61914-2Z 70 100 16 23.7 21.1 6000 7000 0.336
6014-Z 6014-2Z 70 110 20 38.5 30.5 5600 6700 0.57
6214-Z 6214-2Z 70 125 24 60.8 45 4800 6000 1.04
6314-Z 6314-2Z 70 150 35 105 68 4300 5000 2.6
61815-Z 61815-2Z 75 95 10 12.5 12.8 6000 7000 0.147
61915-Z 61915-2Z 75 105 16 24.3 22.5 5600 6700 0.355
6015-Z 6015-2Z 75 115 20 40.2 33.2 5300 6300 0.64
6215-Z 6215-2Z 75 130 25 66 49.5 4500 5600 1.18
6315-Z 6315-2Z 75 160 37 113 76.8 4000 4800 3.05
61816-Z 61816-2Z 80 100 10 12.7 13.3 5600 6700 0.155
61916-Z 61916-2Z 80 110 16 24.9 23.9 5300 6300 0.375
6016-Z 6016-2Z 80 125 22 47.5 39.8 5000 6000 0.83
6216-Z 6216-2Z 80 140 26 71.5 54.2 4300 5300 1.38
6316-Z 6316-2Z 80 170 39 123 86.5 3800 4500 3.62
61817-Z 61817-2Z 85 110 13 19.2 19.8 5000 6300 0.245
61917-Z 61917-2Z 85 120 18 31.9 29.7 4800 6000 0.507
6017-Z 6017-2Z 85 130 22 50.8 42.8 4500 5600 0.86
6217-Z 6217-2Z 85 150 28 83.2 63.8 4000 5000 1.75
6317-Z 6317-2Z 85 180 41 132 96.5 3600 4300 4.27
61818-Z 61818-2Z 90 115 13 19.5 20.5 4800 6000 0.258
61918-Z 61918-2Z 90 125 18 32.8 31.5 4500 5600 0.533
6018-Z 6018-2Z 90 140 24 50.8 49.8 4300 5300 1.1
6218-Z 6218-2Z 90 160 30 95.8 71.5 3800 4800 2.2
61819-Z 61819-2Z 95 120 13 19.8 21.3 4500 5600 0.27
61919-Z 61919-2Z 95 130 18 33.7 33.3 4300 5300 0.558
6019-Z 6019-2Z 95 145 24 57.8 50 4000 5000 1.14
6219-Z 6219-2Z 95 170 32 110 82.8 3600 4500 2.62
61820-Z 61820-2Z 100 125 13 20.1 22 4300 5300 0.283
61920-Z 61920-2Z 100 140 20 42.7 41.9 4000 5000 0.774
6020-Z 6020-2Z 100 150 24 64.5 56.2 3800 4800 1.25
6220-Z 6220-2Z 100 180 34 122 92.8 3400 4300 3.2
61821-Z 61821-2Z 105 130 13 20.3 22.7 4000 5000 0.295
61921-Z 61921-2Z 105 145 20 43.9 44.3 3800 4800 0.808
6021-Z 6021-2Z 105 160 26 71.8 63.2 3600 4500 1.52
61822-Z 61822-2Z 110 140 16 28.1 30.7 3800 5000 0.496
61922-Z 61922-2Z 110 150 20 43.6 44.4 3600 4500 0.835
6022-Z 6022-2Z 110 170 28 81.8 72.8 3400 4300 1.87
61824-Z 61824-2Z 120 150 16 28.9 32.9 3400 4300 0.536
61924-Z 61924-2Z 120 165 22 55 56.9 3200 4000 1.131
6024-Z 6024-2Z 120 180 28 87.5 79.2 3000 3800 2
61826-Z 61826-2Z 130 165 18 37.9 42.9 3200 4000 0.736
61926-Z 61926-2Z 130 180 24 65.1 67.2 3000 3800 1.496
61828-Z 61828-2Z 140 175 18 38.2 44.3 3000 3800 0.784

Sealed Deep Groove Ball Bearing Size Chart

RZ / RS Type Bearing Model 2RZ / 2RS Type Bearing Model Bore Diameter (mm) Outside Diameter (mm) Bearing Width (mm) Basic Dynamic Load Rating (kN) Basic Static Load Rating (kN) Grease Limiting Speed (r/min) Oil Limiting Speed (r/min) Approximate Mass (kg)
61800-RS 61800-2RS 10 19 5 1.8 0.93 21000 — 0.005
61800-RZ 61800-2RZ 10 19 5 1.8 0.93 28000 36000 0.005
61900-RS 61900-2RS 10 22 6 2.7 1.3 19000 — 0.008
61900-RZ 61900-2RZ 10 22 6 2.7 1.3 25000 32000 0.008
6000-RS 6000-2RS 10 26 8 4.58 1.98 15000 — 0.019
6000-RZ 6000-2RZ 10 26 8 4.58 1.98 22000 28000 0.019
6200-RS 6200-2RS 10 30 9 5.1 2.38 14000 — 0.032
6200-RZ 6200-2RZ 10 30 9 5.1 2.38 20000 26000 0.032
6300-RS 6300-2RS 10 35 11 7.65 3.48 12000 — 0.053
6300-RZ 6300-2RZ 10 35 11 7.65 3.48 18000 24000 0.053
61801-RS 61801-2RS 12 21 5 1.9 1 18000 — 0.007
61801-RZ 61801-2RZ 12 21 5 1.9 1 24000 32000 0.007
61901-RS 61901-2RS 12 24 6 2.9 1.5 17000 — 0.013
61901-RZ 61901-2RZ 12 24 6 2.9 1.5 22000 28000 0.013
6001-RS 6001-2RS 12 28 8 5.1 2.38 14000 — 0.02
6001-RZ 6001-2RZ 12 28 8 5.1 2.38 20000 26000 0.02
6201-RS 6201-2RS 12 32 10 6.82 3.05 13000 — 0.04
6201-RZ 6201-2RZ 12 32 10 6.82 3.05 19000 24000 0.04
6301-RS 6301-2RS 12 37 12 9.72 5.08 12000 — 0.06
6301-RZ 6301-2RZ 12 37 12 9.72 5.08 17000 22000 0.06
61802-RS 61802-2RS 15 24 5 2.1 1.3 17000 — 0.005
61802-RZ 61802-2RZ 15 24 5 2.1 1.3 22000 30000 0.005
61902-RS 61902-2RS 15 28 7 4.3 2.3 15000 — 0.012
61902-RZ 61902-2RZ 15 28 7 4.3 2.3 20000 26000 0.012
6002-RS 6002-2RS 15 32 9 5.58 2.85 13000 — 0.03
6002-RZ 6002-2RZ 15 32 9 5.58 2.85 19000 24000 0.03
6202-RS 6202-2RS 15 35 11 7.65 3.72 12000 — 0.04
6202-RZ 6202-2RZ 15 35 11 7.65 3.72 18000 22000 0.04
6302-RS 6302-2RS 15 42 13 11.5 5.42 11000 — 0.08
6302-RZ 6302-2RZ 15 42 13 11.5 5.42 16000 20000 0.08
61803-RS 61803-2RS 17 26 5 2.2 1.5 15000 — 0.007
61803-RZ 61803-2RZ 17 26 5 2.2 1.5 20000 28000 0.007
61903-RS 61903-2RS 17 30 7 4.6 2.6 14000 — 0.014
61903-RZ 61903-2RZ 17 30 7 4.6 2.6 19000 24000 0.014
6003-RS 6003-2RS 17 35 10 6 3.25 12000 — 0.04
6003-RZ 6003-2RZ 17 35 10 6 3.25 17000 21000 0.04
6203-RS 6203-2RS 17 40 12 9.58 4.78 11000 — 0.06
6203-RZ 6203-2RZ 17 40 12 9.58 4.78 16000 20000 0.06
6303-RS 6303-2RS 17 47 14 13.5 6.58 10000 — 0.11
6303-RZ 6303-2RZ 17 47 14 13.5 6.58 15000 18000 0.11
61804-RS 61804-2RS 20 32 7 3.5 2.2 14000 — 0.015
61804-RZ 61804-2RZ 20 32 7 3.5 2.2 18000 24000 0.015
61904-RS 61904-2RS 20 37 9 6.4 3.7 13000 — 0.031
61904-RZ 61904-2RZ 20 37 9 6.4 3.7 17000 22000 0.031
6004-RS 6004-2RS 20 42 12 9.38 5.02 11000 — 0.07
6004-RZ 6004-2RZ 20 42 12 9.38 5.02 16000 19000 0.07
6204-RS 6204-2RS 20 47 14 12.8 6.65 9500 — 0.1
6204-RZ 6204-2RZ 20 47 14 12.8 6.65 14000 18000 0.1
6304-RS 6304-2RS 20 52 15 15.8 7.88 9000 — 0.14
6304-RZ 6304-2RZ 20 52 15 15.8 7.88 13000 16000 0.14
61805-RS 61805-2RS 25 37 7 4.3 2.9 12000 — 0.017
61805-RZ 61805-2RZ 25 37 7 4.3 2.9 16000 20000 0.017
61905-RS 61905-2RS 25 42 9 7 4.5 11000 — 0.038
61905-RZ 61905-2RZ 25 42 9 7 4.5 14000 18000 0.038
6005-RS 6005-2RS 25 47 12 10 5.85 9000 — 0.08
6005-RZ 6005-2RZ 25 47 12 10 5.85 13000 17000 0.08
6205-RS 6205-2RS 25 52 15 14 7.88 8000 — 0.12
6205-RZ 6205-2RZ 25 52 15 14 7.88 12000 15000 0.12
6305-RS 6305-2RS 25 62 17 22.2 11.5 6800 — 0.22
6305-RZ 6305-2RZ 25 62 17 22.2 11.5 10000 14000 0.22
61806-RS 61806-2RS 30 42 7 4.7 3.6 11000 — 0.019
61806-RZ 61806-2RZ 30 42 7 4.7 3.6 13000 17000 0.019
61906-RS 61906-2RS 30 47 9 7.2 5 9000 — 0.043
61906-RZ 61906-2RZ 30 47 9 7.2 5 12000 16000 0.043
6006-RS 6006-2RS 30 55 13 13.2 8.3 7500 — 0.12
6006-RZ 6006-2RZ 30 55 13 13.2 8.3 11000 14000 0.12
6206-RS 6206-2RS 30 62 16 19.5 11.5 6700 — 0.19
6206-RZ 6206-2RZ 30 62 16 19.5 11.5 9500 13000 0.19
6306-RS 6306-2RS 30 72 19 27 15.2 6000 — 0.35
6306-RZ 6306-2RZ 30 72 19 27 15.2 9000 11000 0.35
61807-RS 61807-2RS 35 47 7 4.9 4 9000 — 0.023
61807-RZ 61807-2RZ 35 47 7 4.9 4 11000 15000 0.023
61907-RS 61907-2RS 35 55 10 9.5 6.8 7500 — 0.078
61907-RZ 61907-2RZ 35 55 10 9.5 6.8 10000 13000 0.078
6007-RS 6007-2RS 35 62 14 16.2 10.5 6500 — 0.16
6007-RZ 6007-2RZ 35 62 14 16.2 10.5 9500 12000 0.16
6207-RS 6207-2RS 35 72 17 25.5 15.2 5800 — 0.27
6207-RZ 6207-2RZ 35 72 17 25.5 15.2 8500 11000 0.27
6307-RS 6307-2RS 35 80 21 33.4 19.2 5400 — 0.42
6307-RZ 6307-2RZ 35 80 21 33.4 19.2 8000 9500 0.42
61808-RS 61808-2RS 40 52 7 5.1 4.4 7500 — 0.026
61808-RZ 61808-2RZ 40 52 7 5.1 4.4 10000 13000 0.026
61908-RS 61908-2RS 40 62 12 13.7 9.9 7000 — 0.103
61908-RZ 61908-2RZ 40 62 12 13.7 9.9 9500 12000 0.103
6008-RS 6008-2RS 40 68 15 17 11.8 6000 — 0.19
6008-RZ 6008-2RZ 40 68 15 17 11.8 9000 11000 0.19
6208-RS 6208-2RS 40 80 18 29.5 18 5400 — 0.37
6208-RZ 6208-2RZ 40 80 18 29.5 18 8000 10000 0.37
6308-RS 6308-2RS 40 90 23 40.8 24 4800 — 0.63
6308-RZ 6308-2RZ 40 90 23 40.8 24 7000 8500 0.63
61809-RS 61809-2RS 45 58 7 6.4 5.6 6800 — 0.03
61809-RZ 61809-2RZ 45 58 7 6.4 5.6 9000 12000 0.03
61909-RS 61909-2RS 45 68 12 14.1 10.9 6400 — 0.123
61909-RZ 61909-2RZ 45 68 12 14.1 10.9 8500 11000 0.123
6009-RS 6009-2RS 45 75 16 21 14.8 5400 — 0.24
6009-RZ 6009-2RZ 45 75 16 21 14.8 8000 10000 0.24
6209-RS 6209-2RS 45 85 19 31.5 20.5 4800 — 0.42
6209-RZ 6209-2RZ 45 85 19 31.5 20.5 4300 9000 0.42
6309-RS 6309-2RS 45 100 25 52.8 31.8 6300 — 0.83
6309-RZ 6309-2RZ 45 100 25 52.8 31.8 6300 7500 0.83
61810-RS 61810-2RS 50 65 7 6.6 6.1 6400 — 0.043
61810-RZ 61810-2RZ 50 65 7 6.6 6.1 8500 10000 0.043
61910-RS 61910-2RS 50 72 12 14.5 11.7 6000 — 0.122
61910-RZ 61910-2RZ 50 72 12 14.5 11.7 8000 9500 0.122
6010-RS 6010-2RS 50 80 16 22 16.2 4800 — 0.28
6010-RZ 6010-2RZ 50 80 16 22 16.2 7000 9000 0.28
6210-RS 6210-2RS 50 90 20 35 23.2 4600 — 0.47
6210-RZ 6210-2RZ 50 90 20 35 23.2 6700 8500 0.47
6310-RS 6310-2RS 50 110 27 61.8 38 4100 — 1.08
6310-RZ 6310-2RZ 50 110 27 61.8 38 6000 7000 1.08
61811-RS 61811-2RS 55 72 9 9.1 8.4 6000 — 0.07
61811-RZ 61811-2RZ 55 72 9 9.1 8.4 8000 9500 0.07
61911-RS 61911-2RS 55 80 13 15.9 13.2 5600 — 0.17
61911-RZ 61911-2RZ 55 80 13 15.9 13.2 7500 9000 0.17
6011-RS 6011-2RS 55 90 18 30.2 21.8 4800 — 0.38
6011-RZ 6011-2RZ 55 90 18 30.2 21.8 7000 8500 0.38
6211-RS 6211-2RS 55 100 21 43.2 29.2 4100 — 0.58
6211-RZ 6211-2RZ 55 100 21 43.2 29.2 6000 7500 0.58
6311-RS 6311-2RS 55 120 29 71.5 44.8 3800 — 1.37
6311-RZ 6311-2RZ 55 120 29 71.5 44.8 5600 6700 1.37
61812-RS 61812-2RS 60 78 10 9.1 8.7 5300 — 0.093
61812-RZ 61812-2RZ 60 78 10 9.1 8.7 7000 8500 0.093
61912-RS 61912-2RS 60 85 13 16.4 14.2 5000 — 0.181
61912-RZ 61912-2RZ 60 85 13 16.4 14.2 6700 8000 0.181
6012-RS 6012-2RS 60 95 18 31.5 24.2 4300 — 0.41
6012-RZ 6012-2RZ 60 95 18 31.5 24.2 6300 7500 0.41
6212-RS 6212-2RS 60 110 22 47.8 32.8 3800 — 0.77
6212-RZ 6212-2RZ 60 110 22 47.8 32.8 5600 7000 0.77
6312-RS 6312-2RS 60 130 31 81.8 51.8 3400 — 1.71
6312-RZ 6312-2RZ 60 130 31 81.8 51.8 5000 6000 1.71
61813-RS 61813-2RS 65 85 10 11.9 11.5 5000 — 0.13
61813-RZ 61813-2RZ 65 85 10 11.9 11.5 6700 8000 0.13
61913-RS 61913-2RS 65 90 13 17.4 16 4700 — 0.196
61913-RZ 61913-2RZ 65 90 13 17.4 16 6300 7500 0.196
6013-RS 6013-2RS 65 100 18 32 24.8 4100 — 0.41
6013-RZ 6013-2RZ 65 100 18 32 24.8 6000 7000 0.41
6213-RS 6213-2RS 65 120 23 57.2 40 3400 — 0.98
6213-RZ 6213-2RZ 65 120 23 57.2 40 5000 6300 0.98
6313-RS 6313-2RS 65 140 33 93.8 60.5 3000 — 2.09
6313-RZ 6313-2RZ 65 140 33 93.8 60.5 4500 5300 2.09
61814-RS 61814-2RS 70 90 10 12.1 11.9 4700 — 0.138
61814-RZ 61814-2RZ 70 90 10 12.1 11.9 6300 7500 0.138
61914-RS 61914-2RS 70 100 16 23.7 21.1 4500 — 0.336
61914-RZ 61914-2RZ 70 100 16 23.7 21.1 6000 7000 0.336
6014-RS 6014-2RS 70 110 20 38.5 30.5 3800 — 0.6
6014-RZ 6014-2RZ 70 110 20 38.5 30.5 5600 6700 0.6
6214-RS 6214-2RS 70 125 24 60.8 45 3300 — 1.04
6214-RZ 6214-2RZ 70 125 24 60.8 45 4800 6000 1.04
6314-RS 6314-2RS 70 150 35 105 68 2900 — 2.6
6314-RZ 6314-2RZ 70 150 35 105 68 4300 5000 2.6
61815-RS 61815-2RS 75 95 10 12.5 12.8 4500 — 0.147
61815-RZ 61815-2RZ 75 95 10 12.5 12.8 6000 7000 0.147
61915-RS 61915-2RS 75 105 16 24.3 22.5 4200 — 0.355
61915-RZ 61915-2RZ 75 105 16 24.3 22.5 5600 6700 0.355
6015-RS 6015-2RS 75 115 20 40.2 33.2 3600 — 0.64
6015-RZ 6015-2RZ 75 115 20 40.2 33.2 5300 6300 0.64
6215-RS 6215-2RS 75 130 25 66 49.5 3000 — 1.18
6215-RZ 6215-2RZ 75 130 25 66 49.5 4500 5600 1.18
6315-RS 6315-2RS 75 160 37 113 76.8 2800 — 3
6315-RZ 6315-2RZ 75 160 37 113 76.8 4000 4800 3
61816-RS 61816-2RS 80 100 10 12.7 13.3 4200 — 0.155
61816-RZ 61816-2RZ 80 100 10 12.7 13.3 5600 6700 0.155
61916-RS 61916-2RS 80 110 16 24.9 23.9 4000 — 0.375
61916-RZ 61916-2RZ 80 110 16 24.9 23.9 5300 6300 0.375
6016-RS 6016-2RS 80 125 22 47.5 39.8 3400 — 1.05
6016-RZ 6016-2RZ 80 125 22 47.5 39.8 5000 6000 1.05
6216-RS 6216-2RS 80 140 26 71.5 54.2 2900 — 1.38
6216-RZ 6216-2RZ 80 140 26 71.5 54.2 4300 5300 1.38
6316-RS 6316-2RS 80 170 39 123 86.5 2600 — 3.62
6316-RZ 6316-2RZ 80 170 39 123 86.5 3800 4500 3.62
61817-RS 61817-2RS 85 110 13 19.2 19.8 3800 — 0.245
61817-RZ 61817-2RZ 85 110 13 19.2 19.8 5000 6300 0.245
61917-RS 61917-2RS 85 120 18 31.9 29.7 3600 — 0.507
61917-RZ 61917-2RZ 85 120 18 31.9 29.7 4800 6000 0.507
6017-RS 6017-2RS 85 130 22 50.8 42.8 3200 — 1.1
6017-RZ 6017-2RZ 85 130 22 50.8 42.8 4500 5600 1.1
6217-RS 6217-2RS 85 150 28 83.2 63.8 2800 — 1.75
6217-RZ 6217-2RZ 85 150 28 83.2 63.8 4000 5000 1.75
6317-RS 6317-2RS 85 180 41 132 96.5 2400 — 4.27
6317-RZ 6317-2RZ 85 180 41 132 96.5 3600 4300 4.27
61818-RS 61818-2RS 90 115 13 19.5 20.5 3600 — 0.258
61818-RZ 61818-2RZ 90 115 13 19.5 20.5 4800 6000 0.258
61918-RS 61918-2RS 90 125 18 32.8 31.5 3400 — 0.533
61918-RZ 61918-2RZ 90 125 18 32.8 31.5 4500 5600 0.533
6018-RS 6018-2RS 90 140 24 50.8 49.8 3000 — 1.16
6018-RZ 6018-2RZ 90 140 24 50.8 49.8 4300 5300 1.16
6218-RS 6218-2RS 90 160 30 95.8 71.5 2600 — 2.18
6218-RZ 6218-2RZ 90 160 30 95.8 71.5 3800 4800 2.18
6318-RS 6318-2RS 90 190 43 145 108 2200 — 4.96
6318-RZ 6318-2RZ 90 190 43 145 108 3400 4000 4.96
61819-RS 61819-2RS 95 120 13 19.8 21.3 3400 — 0.27
61819-RZ 61819-2RZ 95 120 13 19.8 21.3 4500 5600 0.27
61919-RS 61919-2RS 95 130 18 33.7 33.3 3200 — 0.558
61919-RZ 61919-2RZ 95 130 18 33.7 33.3 4300 5300 0.558
6019-RS 6019-2RS 95 145 24 57.8 50 2800 — 1.21
6019-RZ 6019-2RZ 95 145 24 57.8 50 4000 5000 1.21
6219-RS 6219-2RS 95 170 32 110 82.8 2400 — 2.62
6219-RZ 6219-2RZ 95 170 32 110 82.8 3600 4500 2.62
61820-RS 61820-2RS 100 125 13 20.1 22 3200 — 0.283
61820-RZ 61820-2RZ 100 125 13 20.1 22 4300 5300 0.283
61920-RS 61920-2RS 100 140 20 42.7 41.9 3000 — 0.774
61920-RZ 61920-2RZ 100 140 20 42.7 41.9 4000 5000 0.774
6020-RS 6020-2RS 100 150 24 64.5 56.2 2600 — 1.25
6020-RZ 6020-2RZ 100 150 24 64.5 56.2 3800 4800 1.25
6220-RS 6220-2RS 100 180 34 122 92.8 2200 — 3.2
6220-RZ 6220-2RZ 100 180 34 122 92.8 3400 4300 3.2
61821-RS 61821-2RS 105 130 13 20.3 22.7 3000 — 0.295
61821-RZ 61821-2RZ 105 130 13 20.3 22.7 4000 5000 0.295
61921-RS 61921-2RS 105 145 20 43.9 44.3 2900 — 0.808
61921-RZ 61921-2RZ 105 145 20 43.9 44.3 3800 4800 0.808
6021-RS 6021-2RS 105 160 26 71.8 63.2 2400 — 1.52
6021-RZ 6021-2RZ 105 160 26 71.8 63.2 3600 4500 1.52
61822-RS 61822-2RS 110 140 16 28.1 30.7 2900 — 0.496
61822-RZ 61822-2RZ 110 140 16 28.1 30.7 3800 5000 0.496
61922-RS 61922-2RS 110 150 20 43.6 44.4 2700 — 0.835
61922-RZ 61922-2RZ 110 150 20 43.6 44.4 3600 4500 0.835
6022-RS 6022-2RS 110 170 28 81.8 72.8 2200 — 1.87
6022-RZ 6022-2RZ 110 170 28 81.8 72.8 3400 4300 1.87
61824-RS 61824-2RS 120 150 16 28.9 32.9 2600 — 0.536
61824-RZ 61824-2RZ 120 150 16 28.9 32.9 3400 4300 0.536
61924-RS 61924-2RS 120 165 22 55 56.9 2400 — 1.131
61924-RZ 61924-2RZ 120 165 22 55 56.9 3200 4000 1.131
6024-RS 6024-2RS 120 180 28 87.5 79.2 2000 — 2
6024-RZ 6024-2RZ 120 180 28 87.5 79.2 3000 3800 2

Angular Contact Ball Bearing Size Chart

Bearing Model Bore Diameter (mm) Outside Diameter (mm) Bearing Width (mm) Basic Dynamic Load Rating (kN) Basic Static Load Rating (kN) Grease Limiting Speed (r/min) Oil Limiting Speed (r/min) Approximate Mass (kg)
7000 C 10 26 8 4.92 2.25 1900 2800 0.018
7000 AC 10 26 8 4.75 2.12 1900 2800 0.018
7200 C 10 30 9 5.82 2.95 1800 2600 0.03
7200 AC 10 30 9 5.58 2.82 1800 2600 0.03
7001 C 12 28 8 5.42 2.65 1800 2600 0.02
7001 AC 12 28 8 5.2 2.55 1800 2600 0.02
7201 C 12 32 10 7.35 3.52 1700 2400 0.035
7201 AC 12 32 10 7.1 3.35 1700 2400 0.035
7002 C 15 32 9 6.25 3.42 17000 24000 0.028
7002 AC 15 32 9 5.95 3.25 17000 24000 0.028
7202 C 15 35 11 8.68 4.62 16000 22000 0.043
7202 AC 15 35 11 8.35 4.4 16000 22000 0.043
7003 C 17 35 10 6.6 3.85 16000 22000 0.036
7003 AC 17 35 10 6.3 3.68 16000 22000 0.036
7203 C 17 40 12 10.8 5.95 15000 20000 0.062
7203 AC 17 40 12 10.5 5.65 15000 20000 0.062
7004 C 20 42 12 10.5 6.08 14000 19000 0.064
7004 AC 20 42 12 10 5.78 14000 19000 0.064
7204 C 20 47 14 14.5 8.22 13000 18000 0.1
7204 AC 20 47 14 14 7.82 13000 18000 0.1
7204 B 20 47 14 14 7.85 13000 18000 0.11
7005 C 25 47 12 11.5 7.45 12000 17000 0.074
7005 AC 25 47 12 11.2 7.08 12000 17000 0.074
7205 C 25 52 15 16.5 10.5 11000 16000 0.12
7205 AC 25 52 15 15.8 9.88 11000 16000 0.12
7205 B 25 52 15 15.8 9.45 11000 16000 0.13
7305 B 25 62 17 26.2 15.2 9500 14000 0.3
7006 C 30 55 13 15.2 10.2 9500 14000 0.11
7006 AC 30 55 13 14.5 9.85 9500 14000 0.11
7206 C 30 62 16 23 15 9000 13000 0.19
7206 AC 30 62 16 22 14.2 9000 13000 0.19
7206 B 30 62 16 20.5 13.8 9000 13000 0.21
7306 B 30 72 19 31 19.2 8500 12000 0.37
7007 C 35 62 14 19.5 14.2 8500 12000 0.15
7007 AC 35 62 14 18.5 13.5 8500 12000 0.15
7207 C 35 72 17 30.5 20 8000 11000 0.28
7207 AC 35 72 17 29 19.2 8000 11000 0.28
7207 B 35 72 17 27 18.8 8000 11000 0.3
7307 B 35 80 21 38.2 24.5 7500 10000 0.51
7008 C 40 68 15 20 15.2 8000 11000 0.18
7008 AC 40 68 15 19 14.5 8000 11000 0.18
7208 C 40 80 18 36.8 25.8 7500 10000 0.37
7208 AC 40 80 18 35.2 24.5 7500 10000 0.37
7208 B 40 80 18 32.5 23.5 7500 10000 0.39
7308 B 40 90 23 46.2 30.5 6700 9000 0.67
7408 B 40 110 27 67 47.5 6000 8000 1.4
7201 C 12 32 10 7.35 3.52 1700 2400 0.035
7201 AC 12 32 10 7.1 3.35 1700 2400 0.035
7002 C 15 32 9 6.25 3.42 17000 24000 0.028
7002 AC 15 32 9 5.95 3.25 17000 24000 0.028
7202 C 15 35 11 8.68 4.62 16000 22000 0.043
7202 AC 15 35 11 8.35 4.4 16000 22000 0.043
7003 C 17 35 10 6.6 3.85 16000 22000 0.036
7003 AC 17 35 10 6.3 3.68 16000 22000 0.036
7203 C 17 40 12 10.8 5.95 15000 20000 0.062
7203 AC 17 40 12 10.5 5.65 15000 20000 0.062
7004 C 20 42 12 10.5 6.08 14000 19000 0.064
7004 AC 20 42 12 10 5.78 14000 19000 0.064
7204 C 20 47 14 14.5 8.22 13000 18000 0.1
7204 AC 20 47 14 14 7.82 13000 18000 0.1
7204 B 20 47 14 14 7.85 13000 18000 0.11
7005 C 25 47 12 11.5 7.45 12000 17000 0.074
7005 AC 25 47 12 11.2 7.08 12000 17000 0.074
7205 C 25 52 15 16.5 10.5 11000 16000 0.12
7205 AC 25 52 15 15.8 9.88 11000 16000 0.12
7205 B 25 52 15 15.8 9.45 11000 16000 0.13
7305 B 25 62 17 26.2 15.2 9500 14000 0.3
7006 C 30 55 13 15.2 10.2 9500 14000 0.11
7006 AC 30 55 13 14.5 9.85 9500 14000 0.11
7206 C 30 62 16 23 15 9000 13000 0.19
7206 AC 30 62 16 22 14.2 9000 13000 0.19
7206 B 30 62 16 20.5 13.8 9000 13000 0.21
7306 B 30 72 19 31 19.2 8500 12000 0.37
7007 C 35 62 14 19.5 14.2 8500 12000 0.15
7007 AC 35 62 14 18.5 13.5 8500 12000 0.15
7207 C 35 72 17 30.5 20 8000 11000 0.28
7207 AC 35 72 17 29 19.2 8000 11000 0.28
7207 B 35 72 17 27 18.8 8000 11000 0.3
7307 B 35 80 21 38.2 24.5 7500 10000 0.51
7008 C 40 68 15 20 15.2 8000 11000 0.18
7008 AC 40 68 15 19 14.5 8000 11000 0.18
7208 C 40 80 18 36.8 25.8 7500 10000 0.37
7208 AC 40 80 18 35.2 24.5 7500 10000 0.37
7208 B 40 80 18 32.5 23.5 7500 10000 0.39
7308 B 40 90 23 46.2 30.5 6700 9000 0.67
7408 B 40 110 27 67 47.5 6000 8000 1.4
7009 C 45 75 16 25.8 20.5 7500 10000 0.23
7009 AC 45 75 16 25.8 19.5 7500 10000 0.23
7209 C 45 85 19 38.5 28.5 6700 9000 0.41
7209 AC 45 85 19 36.8 27.2 6700 9000 0.41
7209 B 45 85 19 36 26.2 6700 9000 0.44
7309 B 45 100 25 59.5 39.8 6000 8000 0.9
7010 C 50 80 16 26.5 22 6700 9000 0.25
7010 AC 50 80 16 25.2 21 6700 9000 0.25
7210 C 50 90 20 42.8 32 6300 8500 0.46
7210 AC 50 90 20 40.8 30.5 6300 8500 0.46
7210 B 50 90 20 37.5 29 6300 8500 0.49
7310 B 50 110 27 68.2 48 5600 7500 1.15
7410 B 50 130 31 95.2 64.2 5000 6700 2.08
7011 C 55 90 18 37.2 30.5 6000 8000 0.38
7011 AC 55 90 18 35.2 39.2 6000 8000 0.38
7211 C 55 100 21 52.8 40.5 5600 7500 0.61
7211 AC 55 100 21 50.5 38.5 5600 7500 0.61
7211 B 55 100 21 46.2 36 5600 7500 0.65
7311 B 55 120 29 78.8 56.5 5000 6700 1.45
7012 C 60 95 18 38.2 32.8 5600 7500 0.4
7012 AC 60 95 18 36.2 31.5 5600 7500 0.4
7212 C 60 110 22 61 48.5 5300 7000 0.8
7212 AC 60 110 22 58.2 46.2 5300 7000 0.8
7212 B 60 110 22 56 44.5 5300 7000 0.84
7312 B 60 130 31 90 66.3 4800 6300 1.85
7412 B 60 150 35 118 85.5 4300 5600 3.56
7013 C 65 100 18 40.4 35.5 5300 7000 0.43
7013 AC 65 100 18 38 33.8 5300 7000 0.43
7213 C 65 120 23 69.8 55.2 4800 6300 1
7213 AC 65 120 23 66.5 52.5 4800 6300 1
7213 B 65 120 23 62.5 53.2 4800 6300 1.05
7313 B 65 140 33 102 77.8 4300 5600 2.25
7014 C 70 110 20 48.2 43.5 5000 6700 0.6
7014 AC 70 110 20 45.8 41.5 5000 6700 0.6
7214 C 70 125 24 70.2 60 4500 6700 1.1
7214 AC 70 125 24 69.2 57.5 4500 6700 1.1
7214 B 70 125 24 70.2 57.2 4500 6700 1.15
7314 B 70 150 35 115 87.2 4000 5300 2.75
7015 C 75 115 20 49.5 46.5 4800 6300 0.63
7015 AC 75 115 20 46.8 44.2 4800 6300 0.63
7215 C 75 130 25 79.2 65.8 4300 5600 1.2
7215 AC 75 130 25 75.2 63 4300 5600 1.2
7215 B 75 130 25 72.8 62 4300 5600 1.3
7315 B 75 160 37 125 98.5 3800 5000 3.3
7016 C 80 125 22 58.5 55.8 4500 6000 0.85
7016 AC 80 125 22 55.5 53.2 4500 6000 0.85
7216 C 80 140 26 89.5 78.2 4000 5300 1.45
7216 AC 80 140 26 85 74.5 4000 5300 1.45
7216 B 80 140 26 80.2 69.5 4000 5300 1.55
7316 B 80 170 39 135 110 3600 4800 3.9
7017 C 85 130 22 62.5 60.2 4300 5600 0.89
7017 AC 85 130 22 59.2 57.2 4300 5600 0.89
7217 C 85 150 28 99.8 85 3800 5000 1.8
7217 AC 85 150 28 94.8 81.5 3800 5000 1.8
7217 B 85 150 28 93 81.5 3800 5000 1.95
7317 B 85 180 41 148 122 3400 4500 4.6
7018 C 90 140 24 71.5 69.8 4000 5300 1.15
7018 AC 90 140 24 67.5 66.5 4000 5300 1.15
7218 C 90 160 30 122 105 3600 4800 2.25
7218 AC 90 160 30 118 100 3600 4800 2.25
7218 B 90 160 30 105 94.5 3600 4800 2.4
7318 B 90 190 43 158 138 3200 4300 5.4
7019 C 95 145 24 73.5 73.2 3800 5000 1.2
7019 AC 95 145 24 69.5 69.8 3800 5000 1.2
7219 C 95 170 32 135 115 3400 4500 2.7
7219 AC 95 170 32 128 108 3400 4500 2.7
7219 B 95 170 32 120 108 3400 4500 2.9
7319 B 95 200 45 172 155 3000 4000 6.25
7020 C 100 150 24 79.2 78.5 3800 5000 1.25
7020 AC 100 150 24 75 74.8 3800 5000 1.25
7220 C 100 180 34 148 128 3200 4300 3.25
7220 AC 100 180 34 142 122 3200 4300 3.25
7220 B 100 180 34 130 115 2600 3600 3.45
7320 B 100 215 47 188 180 2400 3400 7.75
7021 C 105 160 26 88.5 88.8 3600 4800 1.6
7021 AC 105 160 26 83.8 84.2 3600 4800 1.6
7221 C 105 190 36 162 145 3000 4000 3.85
7221 AC 105 190 36 155 138 3000 4000 3.85
7221 B 105 190 36 142 130 2600 3600 4.1
7321 B 105 225 49 202 195 2200 3200 8.8
7022 C 110 170 28 100 102 3600 4800 1.95
7022 AC 110 170 28 95.5 97.2 3600 4800 1.95
7222 C 110 200 38 175 162 2800 3800 4.55
7222 AC 110 200 38 168 155 2800 3800 4.55
7222 B 110 200 38 155 145 2400 3400 4.8
7322 B 110 240 50 225 225 2000 3000 10.5
7024 C 120 180 28 108 110 2800 3800 2.1
7024 AC 120 180 28 102 105 2800 3800 2.1
7224 C 120 215 40 188 180 2400 3400 5.4
7224 AC 120 215 40 180 172 2400 3400 5.4
7026 C 130 200 33 128 135 2600 3600 3.2
7026 AC 130 200 33 122 128 2600 3600 3.2
7226 C 130 230 40 205 210 2200 3200 6.25
7226 AC 130 230 40 195 200 2200 3200 6.25
7028 C 140 210 33 140 145 2400 3400 3.62
7028 AC 140 210 33 140 150 2200 3200 3.62
7228 C 140 250 42 230 245 1900 2800 9.36
7228 AC 140 250 42 230 235 1900 2800 9.24
7328 B 140 300 62 288 315 1700 2400 22.44
7030 C 150 225 35 160 155 2200 3200 4.83
7030 AC 150 225 35 152 168 2000 3000 4.83
7232 C 160 290 48 262 298 1700 2400 14.5
7232 AC 160 290 48 248 278 1700 2400 14.5
7034 AC 170 260 42 192 222 1800 2600 8.25
7234 C 170 310 52 322 390 1600 2200 19.2
7234 AC 170 310 52 305 368 1600 2200 17.2
7236 C 180 320 52 335 415 1500 2000 18.1
7236 AC 180 320 52 315 388 1500 2000 18.1
7038 AC 190 290 46 215 262 1600 2200 10.7
7040 AC 200 310 51 252 325 1500 2000 14.04
7240 C 200 360 58 360 475 1300 1800 25.2
7240 AC 200 360 58 345 448 1300 1800 25.2
7244 AC 220 400 65 358 482 1100 1600 38.5

Self-aligning Ball Bearing Size Chart

Common Bearing Model K Type Bearing Model Bore Diameter (mm) Outside Diameter (mm) Bearing Width (mm) Basic Dynamic Load Rating (kN) Basic Static Load Rating (kN) Grease Limiting Speed (r/min) Oil Limiting Speed (r/min) Approximate Mass (kg)
1200 1200 K 10 30 9 5.48 1.2 24000 28000 0.035
2200 2200 K 10 30 14 7.12 1.58 24000 28000 0.05
1300 1300 K 10 35 11 7.22 1.62 20000 24000 0.06
2300 2300 K 10 35 17 11 2.45 18000 22000 0.09
1201 1201 K 12 32 10 5.55 1.25 22000 26000 0.042
2201 2201 K 12 32 14 8.8 1.8 22000 26000 —
1301 1301 K 12 37 12 9.42 2.12 18000 22000 0.07
2301 2301 K 12 37 17 12.5 2.72 17000 22000 —
1202 1202 K 15 35 11 7.48 1.75 18000 22000 0.051
2202 2202 K 15 35 14 7.65 1.8 18000 22000 0.06
1302 1302 K 15 42 13 9.5 2.28 16000 20000 0.1
2302 2302 K 15 42 17 12 2.88 14000 18000 0.11
1203 1203 K 17 40 12 7.9 2.02 16000 20000 0.076
2203 2203 K 17 40 16 9 2.45 16000 20000 0.09
1303 1303 K 17 47 14 12.5 3.18 14000 17000 0.14
2303 2303 K 17 47 19 14.5 3.58 13000 16000 0.17
1204 1204 K 20 47 14 9.95 2.65 14000 17000 0.12
2204 2204 K 20 47 18 12.5 3.28 14000 17000 0.15
1304 1304 K 20 52 15 12.5 3.38 12000 15000 0.17
2304 2304 K 20 52 21 17.8 4.75 11000 14000 0.22
1205 1205 K 25 52 15 12 3.3 12000 14000 0.14
2205 2205 K 25 52 18 12.5 3.4 12000 14000 0.19
1305 1305 K 25 62 17 17.8 5.05 10000 13000 0.26
2305 2305 K 25 62 24 24.5 6.48 9500 12000 0.35
1206 1206 K 30 62 16 15.8 4.7 10000 12000 0.23
2206 2206 K 30 62 20 15.2 4.6 10000 12000 0.26
1306 1306 K 30 72 19 21.2 6.28 8500 11000 0.4
2306 2306 K 30 72 27 31.5 8.68 8000 10000 0.5
1207 1207 K 35 72 17 15.8 5.08 8500 10000 0.32
2207 2207 K 35 72 23 21.8 6.65 8500 10000 0.44
1307 1307 K 35 80 21 25.6 7.95 7500 9500 0.545
2307 2307 K 35 80 31 39.2 11 7100 9000 0.68
1208 1208 K 40 80 18 19.2 6.4 7500 9000 0.41
2208 2208 K 40 80 23 22.5 7.38 7500 9000 0.53
1308 1308 K 40 90 23 29.5 9.5 6700 8500 0.71
2308 2308 K 40 90 33 44.8 13.2 6300 8000 0.93
1209 1209 K 45 85 19 21.8 7.32 7100 8500 0.49
2209 2209 K 45 85 23 23.2 8 7100 8500 0.55
1309 1309 K 45 100 25 38.8 12.8 6000 7500 0.96
2309 2309 K 45 100 36 55 16.2 5600 7100 1.25
1210 1210 K 50 90 20 22.8 8.08 6300 8000 0.54
2210 2210 K 50 90 23 23.2 8.45 6300 8000 0.68
1310 1310 K 50 110 27 43.2 14.2 5600 6700 1.21
2310 2310 K 50 110 40 64.5 19.8 5000 6300 1.64
1211 1211 K 55 100 21 26.8 10 6000 7100 0.72
2211 2211 K 55 100 25 26.8 9.95 6000 7100 0.81
1311 1311 K 55 120 29 51.5 18.2 5000 6300 1.58
2311 2311 K 55 120 43 75.2 23.5 4800 6000 2.1
1212 1212 K 60 110 22 30.2 11.5 5300 6300 0.91
2212 2212 K 60 110 28 34 12.5 5300 6300 1.1
1312 1312 K 60 130 31 57.2 20.8 4500 5600 1.96
2312 2312 K 60 130 46 86.8 27.5 4300 5300 2.6
1213 1213 K 65 120 23 31 12.5 4800 6000 0.92
2213 2213 K 65 120 31 43.5 16.2 4800 6000 1.5
1313 1313 K 65 140 33 61.8 23.8 4300 5300 2.39
2313 2313 K 65 140 48 96 32.5 3800 4800 3.2
1214 1214 K 70 125 24 34.5 13.5 4800 5600 1.29
1214 M 1214 KM 70 125 24 34.5 13.5 4800 5600 1.315
2214 2214 K 70 125 31 44 17 4500 5600 1.62
2214 K 2214 KM 70 125 31 45.2 20.8 4500 5600 1.575
1314 1314 K 70 150 35 74.5 27.5 4000 5000 3
1314 M 1314 KM 70 150 35 75 28.5 4000 5000 3.267
2314 2314 K 70 150 51 110 37.5 3600 4500 3.9
2314 M 2314 KM 70 150 51 112 37.2 3600 4500 5.358
1215 1215 K 75 130 25 38.8 15.2 4300 5300 1.35
1215 M 1215 KM 75 130 25 38.8 15.2 4300 5300 1.461
2215 2215 K 75 130 31 44.2 18 4300 5300 1.72
1315 1315 K 75 160 37 79 29.8 3800 4500 3.6
1315 M 1315 KM 75 160 37 81.5 31.5 3800 4500 3.911
2315 2315 K 75 160 55 122 42.8 3400 4300 4.7
2315 M 2315 KM 75 160 55 125 42.2 3400 4300 6.535
1216 1216 K 80 140 26 39.5 16.8 4000 5000 1.65
1216 M 1216 KM 80 140 26 39.5 16.2 4000 5000 1.792
2216 2216 K 80 140 33 48.8 20.2 4000 5000 2.19
1316 1316 K 80 170 39 88.5 32.8 3600 4300 4.2
1316 M 1316 KM 80 170 39 89.8 35 3600 4300 4.652
2316 2316 K 80 170 58 128 45.5 3200 4000 5.7
2316 M 2316 KM 80 170 58 135 47.5 3200 4000 7.785
1217 1217 K 85 150 28 48.8 20.5 3800 4500 2.1
1217 M 1217 KM 85 150 28 47.8 19.5 3800 4500 2.24
2217 2217 K 85 150 36 58.2 23.5 3800 4500 2.53
1317 1317 K 85 180 41 97.8 37.8 3400 4000 5
1317 M 1317 KM 85 180 41 97.8 38.5 3400 4000 5.475
2317 2317 K 85 180 60 140 51.5 3000 3800 6.7
2317 M 2317 KM 85 180 60 140 51.5 3000 3800 8.982
1218 1218 K 90 160 30 56.5 23.2 3600 4300 2.5
1218 M 1218 KM 90 160 30 52.5 21.7 3600 4300 2.753
2218 2218 K 90 160 40 70 28.5 3600 4300 3.22
2218 M 2218 KM 90 160 40 70.2 28.5 3600 4300 4.073
1318 1318 K 90 190 43 115 44.5 3200 3800 6
1318 M 1318 KM 90 190 43 115.8 46 3200 3800 6.418
2318 2318 K 90 190 64 142 57.2 2800 3600 7.9
2318 M 2318 KM 90 190 64 152 57.8 2800 3600 10.722
1219 1219 K 95 170 32 63.5 27 3400 4000 3
1219 M 1219 KM 95 170 32 63.8 28.6 3400 4000 3.314
2219 2219 K 95 170 43 82.8 33.8 3400 4000 4.3
2219 M 2219 KM 95 170 43 83.2 34.2 3400 4000 5.024
1319 1319 K 95 200 45 132 50.8 3000 3600 7
1319 M 1319 KM 95 200 45 125 50.2 3000 3600 7.45
2319 2319 K 95 200 67 162 64.2 2800 3400 9.2
2319 M 2319 KM 95 200 67 165 64.2 2800 3400 12.414
1220 1220 K 100 180 34 68.5 29.2 3200 3800 3.7
1220 M 1220 KM 100 180 34 69.2 29.5 3200 3800 3.979
2220 2220 K 100 180 46 97.2 40.5 3200 3800 5
2220 M 2220 KM 100 180 46 97.5 40.5 3200 3800 6.605
1320 1320 K 100 215 47 142 57.2 2800 3400 8.64
1320 M 1320 KM 100 215 47 145 59.5 2800 3400 9.24
2320 2320 K 100 215 73 192 78.5 2400 3200 12.4
2320 M 2320 KM 100 215 73 192 78.5 2400 3200 15.949
1221 1221 K 105 190 36 74 32.2 3000 3600 4.4
1221 M 1221 KM 105 190 36 74.5 32.2 3000 3600 4.727
2221 2221 K 105 190 50 — — 3000 3600 —
2221 M 2221 KM 105 190 50 101 46.5 3000 3600 7.391
1321 1321 K 105 225 49 152 64.5 2600 3200 9.55
1321 M 1321 KM 105 225 49 150 63.5 2600 3200 10.544
2321 M 2321 KM 105 225 77 218 92.5 2400 3000 18.485
1222 1222 K 110 200 38 87.2 37.5 2800 3400 5.2
1222 M 1222 KM 110 200 38 88 38.5 2800 3400 5.578
2222 2222 K 110 200 53 125 52.2 2800 3400 7.2
2222 M 2222 KM 110 200 53 125 52.2 2800 3400 8.759
1322 1322 K 110 240 50 162 72.8 2400 3000 11.8
1322 M 1322 KM 110 240 50 162 72.5 2400 3000 12.452
2322 2322 K 110 240 80 215 94.2 2200 2800 17.6
2322 M 2322 KM 110 240 80 215 94.2 2200 2800 21.967

Thrust Ball Bearing Size Chart

There are many types of the thrust ball bearings. Here, I will list the most popular ones.

Single Direction Thrust Ball Bearings

Bearing Model Bore Diameter d (mm) Outside Diameter D (mm) Bearing Height T (mm) Basic Dynamic Axial Load Rating Ca (kN) Basic Static Axial Load Rating C0a (kN) Minimum Load Factor A Limiting Speed with Grease Lubrication (r/min) Limiting Speed with Oil Lubrication (r/min) Approximate Mass W (kg)
51100 10 24 9 10.0 14.0 0.001 6300 9000 0.019
51200 10 26 11 12.5 17.0 0.002 6000 8000 0.028
51101 12 26 9 10.2 15.2 0.001 6000 8500 0.021
51201 12 28 11 13.2 19.0 0.002 5300 7500 0.031
51102 15 28 9 10.5 16.8 0.002 5600 8000 0.022
51202 15 32 12 16.5 24.8 0.003 4800 6700 0.041
51103 17 30 9 10.8 18.2 0.002 5300 7500 0.024
51203 17 35 12 17.0 27.2 0.004 4500 6300 0.048
51104 20 35 10 14.2 24.5 0.004 4800 6700 0.036
51204 20 40 14 22.2 37.5 0.007 3800 5300 0.075
51304 20 47 18 35.0 55.8 0.016 3600 4500 0.150
51105 25 42 11 15.2 30.2 0.005 4300 6000 0.055
51205 25 47 15 27.8 50.5 0.013 3400 4800 0.110
51305 25 52 18 35.5 61.5 0.021 3000 4300 0.170
51405 25 60 24 55.5 89.2 0.044 2200 3400 0.310
51106 30 47 11 16.0 34.2 0.007 4000 5600 0.062
51206 30 52 16 28.0 54.2 0.016 3200 4500 0.130
51306 30 60 21 42.8 78.5 0.033 2400 3600 0.260
51406 30 70 28 72.5 125.0 0.082 1900 3000 0.510
51107 35 52 12 18.2 41.5 0.010 3800 5300 0.077
51207 35 62 18 39.2 78.2 0.033 2800 4000 0.210
51307 35 68 24 55.2 105.0 0.059 2000 3200 0.370
51407 35 80 32 86.8 155.0 0.130 1700 2600 0.760
51108 40 60 13 26.8 62.8 0.021 3400 4800 0.110
51208 40 68 19 47.0 98.2 0.050 2400 3600 0.260
51308 40 78 26 69.2 135.0 0.096 1900 3000 0.530
51408 40 90 36 112.0 205.0 0.220 1500 2200 1.060
51109 45 65 14 27.0 66.0 0.024 3200 4500 0.140
51209 45 73 20 47.8 105.0 0.059 2200 3400 0.300
51309 45 85 28 75.8 150.0 0.130 1700 2600 0.660
51409 45 100 39 140 262 0.36 1400 2000 1.41
51110 50 70 14 27.2 69.2 0.027 3000 4300 0.15
51210 50 78 22 48.5 112 0.068 2000 3200 0.37
51310 50 95 31 96.5 202 0.21 1600 2400 0.92
51410 50 110 43 160 302 0.5 1300 1900 1.86
51111 55 78 16 33.8 89.2 0.043 2800 4000 0.22
51211 55 90 25 67.5 158 0.13 1900 3000 0.58
51311 55 105 35 115 242 0.31 1500 2200 1.28
51411 55 120 48 182 355 0.68 1100 1700 2.51
51112 60 85 17 40.2 108 0.063 2600 3800 0.27
51212 60 95 26 73.5 178 0.16 1800 2800 0.66
51312 60 110 35 118 262 0.35 1400 2000 1.37
51412 60 130 51 200 395 0.88 1000 1600 3.08
51113 65 90 18 40.5 112 0.07 2400 3600 0.31
51213 65 100 27 74.8 188 0.18 1700 2600 0.72
51313 65 115 36 115 262 0.38 1300 1900 1.48
51413 65 140 56 215 448 1.14 900 1400 3.91
51114 70 95 18 40.8 115 0.078 2200 3400 0.33
51214 70 105 27 73.5 188 0.19 1600 2400 0.75
51314 70 125 40 148 340 0.6 1200 1800 1.98
51414 70 150 60 255 560 1.71 850 1300 4.85
51115 75 100 19 48.2 140 0.11 2000 3200 0.38
51215 75 110 27 74.8 198 0.21 1500 2200 0.82
51315 75 135 44 162 380 0.77 1100 1700 2.58
51415 75 160 65 268 615 2 800 1200 6.08
51116 80 105 19 48.5 145 0.12 1900 3000 0.4
51216 80 115 28 83.8 222 0.27 1400 2000 0.9
51316 80 140 44 160 380 0.81 1000 1600 2.69
51416 80 170 68 292 692 2.55 750 1100 7.12
51117 85 110 19 49.2 150 0.13 1800 2800 0.42
51217 85 125 31 102 280 0.41 1300 1900 1.21
51317 85 150 49 208 495 1.28 950 1500 3.47
51417 85 180 72 318 782 3.24 700 1000 8.28
51118 90 120 22 65 200 0.21 1700 2600 0.65
51218 90 135 35 115 315 0.52 1200 1800 1.65
51318 90 155 50 205 495 1.34 900 1400 3.69
51418 90 190 77 325 825 3.71 670 950 9.86
51120 100 135 25 85 268 0.37 1600 2400 0.95
51220 100 150 38 132 375 0.75 1100 1700 2.21
51320 100 170 55 235 595 1.88 800 1200 4.86
51420 100 210 85 400 1080 6.17 600 850 13.3
51122 110 145 25 87 288 0.43 1500 2200 1.03
51222 110 160 38 138 412 0.89 1000 1600 2.39
51322 110 190 63 278 755 2.97 700 1100 7.05
51422 110 230 95 490 1390 10.4 530 750 20
51124 120 155 25 87 298 0.48 1400 2000 1.1
51224 120 170 39 135 412 0.96 950 1500 2.62
51324 120 210 70 330 945 4.58 670 950 9.54
51424 120 250 102 412 1220 12.4 480 670 25.5
51126 130 170 30 108 375 0.74 1300 1900 1.7
51226 130 190 45 188 575 1.75 900 1400 3.93
51326 130 225 75 358 1070 5.91 600 850 11.7
51426 130 270 110 630 2010 21.1 430 600 32
51128 140 180 31 110 402 0.84 1200 1800 1.85
51228 140 200 46 190 598 1.96 850 1300 4.27
51328 140 240 80 395 1230 7.84 560 800 14.1
51428 140 280 112 630 2010 22.2 400 560 32.2
51130 150 190 31 110 415 0.93 1100 1700 1.95
51230 150 215 50 242 768 3.06 800 1200 5.52
51330 150 250 80 405 1310 8.8 530 750 14.9
51430 150 300 120 670 2240 27.9 380 530 38.2
51132 160 200 31 110 428 1.01 1000 1600 2.06
51232 160 225 51 240 768 3.23 750 1100 5.91
51332 160 270 87 470 1570 12.8 500 700 18.9
51134 170 215 34 135 528 1.48 950 1500 2.71
51234 170 240 55 280 915 4.48 700 1000 7.31
51334 170 280 87 470 1580 13.8 480 670 22.5
51136 180 225 34 135 528 1.56 900 1400 2.77
51236 180 250 56 285 958 4.91 670 950 7.84
51336 180 300 95 518 1820 17.9 430 600 28.7
51138 190 240 37 172 678 2.41 850 1300 3.61
51238 190 270 62 328 1160 6.97 630 900 10.5
51338 190 320 105 600 2220 26.7 400 560 41.1
51140 200 250 37 172 698 2.6 800 1200 3.77
51240 200 280 62 332 1210 7.59 600 850 11
51340 200 340 110 608 2220 28 360 500 44
51144 220 270 37 188 782 3.35 750 1100 4.6
51244 220 300 63 365 1360 10.3 560 800 13.7
51148 240 300 45 258 1040 5.95 700 1000 7.6
51248 240 340 78 468 1870 19 450 630 23.6
51348 240 380 112 692 2870 44.1 320 450 51
51152 260 320 45 270 1140 6.99 670 950 8.1
51252 260 360 79 488 2050 22.3 430 600 25.5
51156 280 350 53 338 1430 11.2 560 800 12.2
51256 280 380 80 490 2140 24.7 400 560 27.8
51160 300 380 62 415.0 1860.0 18.5 500 700 17.5
51260 300 420 95 578.0 2670.0 39.3 360 560 42.5
51164 320 400 63 418.0 1920.0 20.2 480 670 18.9
51264 320 440 95 612.0 2920.0 45.3 340 480 45.5
51168 340 420 64 428.0 2050.0 22.7 450 630 20.5
51268 340 460 96 620.0 3040.0 49.6 320 450 52.0
51368 340 540 160 1120.0 5720.0 175.0 150 220 145.0
51172 360 440 65 432.0 2110.0 24.6 430 600 22.0
51272 360 500 110 775.0 3940.0 84.0 260 380 70.9
51176 380 460 65 440.0 2210.0 26.0 430 600 23.0
51276 380 520 112 788.0 4120.0 91.5 240 360 73.0
51180 400 480 65 452.0 2320.0 28.0 400 560 23.7
51280 400 540 112 802.0 4310.0 99.0 220 340 76.0
51184 420 500 65 462.0 2480.0 33.3 380 530 25.2
51188 440 540 80 527.0 3000.0 47.0 360 500 42.0
51288 440 600 130 808.0 4430.0 105.0 180 280 112.0
51192 460 560 80 578.0 3310.0 58.9 320 450 43.0
51292 460 620 130 892.0 5230.0 148.0 170 260 119.0
51196 480 580 80 592.0 3490.0 53.0 300 430 43.9
511/500 500 600 80 595.0 3570.0 68.8 280 400 47.2
512/500 500 670 135 1020.0 6200.0 212.0 150 220 140.0
511/530 530 640 85 708.0 4000.0 80.0 260 380 57.3
512/630 630 850 175 1320.0 9300.0 481.0 100 160 252.0
511/670 670 800 105 860.0 5020.0 206.0 160 240 105.0
511/750 750 900 120 768.0 5900.0 220.0 160 240 112.2

Double Direction Thrust Ball Bearings



Bearing Model Bore Diameter d (mm) Outside Diameter D (mm) Height T1 (mm) Basic Dynamic Load Rating Ca (kN) Basic Static Load Rating C0a (kN) Minimum Load Factor A Limiting Speed with Grease (r/min) Limiting Speed with Oil (r/min) Mass W (kg)
52202 15. 32. 22. 16.5 24.8 0.003 4800. 6700. 0.08
52204 20. 40. 26. 22.2 37.5 0.007 3800. 5300. 0.15
52205 25. 47. 28. 27.8 50.5 0.013 3400. 4800. 0.21
52305 25. 52. 34. 35.5 61.5 0.021 3000. 4300. 0.32
52405 25. 60. 45. 55.5 89.2 0.044 2200. 3400. 0.61
52206 30. 52. 29. 28. 54.2 0.016 3200. 4500. 0.24
52306 30. 60. 38. 42.8 78.5 0.033 2400. 3600. 0.47
52406 30. 70. 52. 72.5 125. 0.082 1900. 3000. 0.97
52207 35. 62. 34. 39.2 78.2 0.033 2800. 4000. 0.41
52307 35. 68. 44. 55.2 105. 0.059 2000. 3200. 0.68
52407 35. 80. 59. 86.8 155. 0.13 1700. 2600. 1.41
52208 40. 68. 36. 47. 98.2 0.05 2400. 3600. 0.53
52308 40. 78. 49. 69.2 135. 0.098 1900. 3000. 1.03
52408 40. 90. 65. 112. 205. 0.22 1500. 2200. 1.94
52209 45. 73. 37. 47.8 105. 0.059 2200. 3400. 0.59
52309 45. 85. 52. 75.8 150. 0.13 1700. 2600. 1.25
52409 45. 100. 72. 140. 262. 0.36 1400. 2000. 2.64
52210 50. 78. 39. 48.5 112. 0.068 2000. 3200. 0.69
52310 50. 95. 58. 96.5 202. 0.21 1600. 2400. 1.76
52410 50. 110. 78. 160. 302. 0.5 1300. 1900. 3.4
52211 55. 90. 45. 67.5 158. 0.13 1900. 3000. 1.17
52311 55. 105. 64. 115. 242. 0.31 1500. 2200. 2.38
52411 55. 120. 87. 182. 355. 0.68 1100. 1700. 4.54
52212 60. 95. 46. 73.5 178. 0.16 1800. 2800. 1.21
52312 60. 110. 64. 118. 262. 0.35 1400. 2000. 2.54
52412 60. 130. 93. 200. 395. 0.88 1000. 1600. 5.58
52413 65. 140. 101. 215. 448. 1.14 900. 1400. 7.07
52213 65. 100. 47. 74.8 188. 0.18 1700. 2600. 1.32
52313 65. 115. 65. 115. 262. 0.38 1300. 1900. 2.72
52214 70. 105. 47. 73.5 188. 0.19 1600. 2400. 1.42
52314 70. 125. 72. 148. 340. 0.6 1200. 1800. 3.64
52414 70. 150. 107. 255. 560. 1.71 850. 1300. 8.71
52215 75. 110. 47. 74.8 198. 0.21 1500. 2200. 1.5
52315 75. 135. 79. 162. 380. 0.77 1100. 1700. 4.72
52415 75. 160. 115. 268. 615. 2. 800. 1200. 10.7
52216 80. 115. 48. 83.8 222. 0.27 1400. 2000. 1.63
52316 80. 140. 79. 160. 380. 0.81 1000. 1600. 4.92
52217 85. 125. 55. 102. 280. 0.41 1300. 1900. 2.27
52317 85. 150. 87. 208. 495. 1.28 950. 1500. 6.26
52417 85. 180. 128. 318. 782. 3.24 700. 1000. 14.8
52218 90. 135. 62. 115. 315. 0.52 1200. 1800. 3.05
52318 90. 155. 88. 205. 495. 1.34 900. 1400. 6.56
52418 90. 190. 135. 325. 825. 3.71 670. 950. 17.3
52220 100. 150. 67. 132. 375. 0.75 1100. 1700. 4.03
52320 100. 170. 97. 235. 595. 1.88 800. 1200. 8.62
52420 100. 210. 150. 400. 1080. 6.17 600. 850. 23.5
52222 110. 160. 67. 138. 412. 0.89 1000. 1600. 4.38
52322 110. 190. 110. 278. 755. 2.97 700. 1100. 12.4
52422 110. 230. 166. 490. 1390. 10.4 530. 750. 33.
52224 120. 170. 68. 135. 412. 0.96 950. 1500. 4.82
52324 120. 210. 123. 330. 945. 4.58 670. 950. 17.1
52226 130. 190. 80. 188. 575. 1.75 900. 1400. 7.36
52326 130. 225. 130. 358. 1070. 5.91 600. 850. 20.8
52426 130. 270. 192. 630. 2010. 21.1 430. 600. 55.
52228 140. 200. 81. 190. 598. 1.96 850. 1300. 7.8
52328 140. 240. 140. 395. 1230. 7.84 560. 800. 25.
52428 140. 280. 196. 630. 2010. 22.2 400. 560. 61.2
52230 150. 215. 89. 242. 768. 3.06 800. 1200. 10.3
52330 150. 250. 140. 405. 1310. 8.8 530. 750. 26.4
52430 150. 300. 209. 670. 2240. 27.9 380. 530. 68.1
52232 160. 225. 90. 240. 768. 3.23 750. 1100. 10.9
52332 160. 270. 153. 470. 1570. 12.8 500. 700. 33.6
52234 170. 240. 97. 280. 915. 4.48 700. 1000. 13.4
52334 170. 280. 153. 470. 1580. 13.8 480. 670. 15.
52236 180. 250. 98. 285. 958. 4.91 670. 950. 14.6
52336 180. 300. 165. 518. 1820. 17.9 430. 600. 49.
52238 190. 270. 109. 328. 1160. 6.97 630. 900. 19.5
52240 200. 280. 109. 332. 1210. 7.59 500. 850. 20.4

Angular Contact Thrust Ball Bearing Size Chart

Bearing Model Bore Diameter d (mm) Outside Diameter D (mm) Width T (mm) Shoulder Diameter d1 Max (mm) Housing Washer Width B (mm) Seat Washer Width C (mm) Chamfer Radius r Min (mm) Chamfer Radius r1 Min (mm) Dynamic Load Rating Ca (kN) Static Load Rating C0a (kN) Limiting Speed Grease (r/min) Limiting Speed Oil (r/min) Mass W (kg)
234405 25. 47. 28. 40. 7. 14. 0.6 0.15 10.19 24.1 7500. 10000. 0.186
234705 27. 47. 28. 40. 7. 14. 0.6 0.15 10.19 24.1 7500. 10000. 0.168
234406 30. 55. 32. 47. 8. 16. 1. 0.15 10.78 28.2 6700. 9000. 0.286
234706 32. 55. 32. 47. 8. 16. 1. 0.15 10.78 28.2 6700. 9000. 0.262
234407 35. 62. 34. 53. 8.5 17. 1. 0.15 15.19 42.1 6000. 8000. 0.375
234707 37. 62. 34. 53. 8.5 17. 1. 0.15 15.19 42.1 6000. 8000. 0.345
234408 40. 68. 36. 58.5 9. 18. 1. 0.15 18.3 49.9 5600. 7500. 0.457
234708 42. 68. 34. 53. 8.5 17. 1. 0.15 18.3 49.9 5600. 7500. 0.419
234409 45. 75. 38. 65. 9.5 19. 1. 0.15 20. 59.8 5300. 7000. 0.551
234709 47. 75. 38. 65. 9.5 19. 1. 0.15 20. 59.8 5300. 7000. 0.51
234410 50. 80. 38. 70. 9.5 19. 1. 0.15 20.5 64.6 5000. 6700. 0.624
234710 52. 80. 38. 70. 9.5 19. 1. 0.15 20.5 64.6 5000. 6700. 0.577
234411 55. 90. 44. 78. 11. 22. 1.1 0.3 28.6 85.7 4500. 6000. 0.949
234711 57. 90. 44. 78. 11. 22. 1.1 0.3 28.6 85.7 4500. 6000. 0.889
234413 65. 100. 44. 88. 11. 22. 1.1 0.3 29.8 97.5 4300. 5600. 1.08
234713 67. 100. 44. 88. 11. 22. 1.1 0.3 29.8 97.5 4300. 5600. 1.01
234414 70. 110. 48. 97. 12. 24. 1.1 0.3 36.2 122.5 3800. 5000. 1.51
234714 73. 110. 48. 97. 12. 24. 1.1 0.3 36.2 122.5 3800. 5000. 1.38
234415 75. 115. 48. 102. 12. 24. 1.1 0.3 37.7 131.3 3800. 5000. 1.59
234715 78. 115. 48. 102. 12. 24. 1.1 0.3 37.7 131.3 3800. 5000. 1.45
234416 80. 125. 54. 110. 13.5 27. 1.1 0.3 44.1 156.8 3400. 4500. 2.23
234716 83. 125. 54. 110. 13.5 27. 1.1 0.3 44.1 156.8 3400. 4500. 2.06
234417 85. 130. 54. 115. 13.5 27. 1.1 0.3 44.6 162.6 3200. 4300. 2.36
234717 88. 130. 54. 115. 13.5 27. 1.1 0.3 44.6 162.6 3200. 4300. 2.18
234418 90. 140. 60. 123. 15. 30. 1.5 0.3 51.9 190. 3000. 4000. 3.01
234718 93. 140. 60. 123. 15. 30. 1.5 0.3 51.9 190. 3000. 4000. 2.81
234419 95. 145. 60. 128. 15. 30. 1.5 0.3 52.4 196.9 2800. 3800. 3.13
234719 98. 145. 60. 128. 15. 30. 1.5 0.3 52.4 196.9 2800. 3800. 2.92
234420 100 150 60 133 15 30 1.5 0.3 52.9 203.8 2800 3800 3.19
234720 103 150 30 133 15 30 1.5 0.3 52.9 203.8 2800 3800 2.97
234421 105 160 66 142 16.5 33 2 0.6 60.2 236.1 2400 3400 4.53
234721 109 160 66 142 16.5 33 2 0.6 60.2 236.1 2400 3400 —
234422 110 170 72 150 18 36 2 0.6 73.5 279.3 2200 3200 5.32
234722 114 170 72 150 18 36 2 0.6 73.5 279.3 2200 3200 —
234424 120 180 72 160 18 36 2 0.6 75.4 298.9 2200 3200 5.54
234724 124 180 72 160 18 36 2 0.6 75.4 298.9 2200 3200 5.11
234426 130 200 84 177 21 42 2 0.6 106.8 406.7 1900 2800 10.1
234726 135 200 84 177 21 42 2 0.6 106.8 406.7 1900 2800 8.9
234428 140 210 84 187 21 42 2.1 0.6 110.7 436.7 1800 2600 9.16
234728 145 210 84 187 21 42 2.1 0.6 110.7 436.7 1800 2600 8.44
234430 150 225 90 200 22.5 45 2.1 0.6 112.7 465.5 1700 2400 11.1
234730 155 225 90 200 22.5 45 2.1 0.6 112.7 465.5 1700 2400 10.3
234432 160 240 96 212 24 48 2.1 0.6 132.3 543.9 1600 2200 13.6
234732 165 240 96 212 24 48 2.1 0.6 132.3 543.9 1600 2200 12.6
234434 170 260 108 230 27 54 2.1 0.6 — — — — 17.7
234734 176 260 108 230 27 54 2.1 0.6 — — — — 16.3
234436 180 280 120 248 30 60 2.1 0.6 — — — — 23.4
234736 187 280 120 248 30 60 2.1 0.6 — — — — 21.5
234438 190 290 120 258 30 60 2.1 0.6 181.3 788.9 1400 1900 25.7
234738 197 290 120 258 30 60 2.1 0.6 181.3 788.9 1400 1900 23.7
234440 200 310 132 274 33 66 2.1 0.6 208.7 916.3 1300 1700 33.6
234740 207 310 132 274 33 66 2.1 0.6 208.7 916.3 1300 1700 31.3
234444 220 340 144 304 36 72 3 1 — — — — —
234744 228 340 144 304 36 72 3 1 — — — — —
234448 240 360 144 322 36 72 3 1 — — — — —
234748 248 360 144 322 36 72 3 1 — — — — —
234452 260 400 164 354 41 82 3 1.5 — — — — —
234752 269 400 164 354 41 82 3 1.5 — — — — —
234456 280 420 164 374 41 82 3 1.5 — — — — —
234756 289 420 164 374 41 82 3 1.5 — — — — —
234460 300 460 190 406 47.5 95 3 1.5 — — — — —
234760 310 460 190 406 47.5 95 3 1.5 — — — — —
234464 320 480 190 426 47.5 95 3 1.5 — — — — —
234764 330 480 190 426 47.5 95 3 1.5 — — — — —
234468 340 520 212 459 53 106 3 1.5 — — — — —
234768 350 520 212 459 53 106 3 1.5 — — — — —
234472 360 540 212 479 53 106 3 1.5 — — — — —
234772 370 540 212 479 53 106 3 1.5 — — — — —
234476 380 560 212 499 53 106 3 1.5 — — — — —
234776 390 560 212 499 53 106 3 1.5 — — — — —
234480 400 600 236 532 59 118 3 1.5 — — — — —
234780 410 600 236 532 59 118 3 1.5 — — — — —

Final Words

With this ball bearing size chart, you can quickly check common ball bearing numbers, bore diameters, outside diameters, widths, load ratings, limiting speeds, and approximate weights.

However, the chart should only be used as a reference. Before purchasing ball bearings, you should confirm the actual bearing size, tolerance, clearance, sealing type, lubrication, and working conditions with the manufacturer.

If you need to buy ball bearings, contact BKZ Industry directly. It can supply deep groove ball bearings, shielded ball bearings, sealed ball bearings, self-aligning ball bearings, angular contact ball bearings, thrust ball bearings, and many other bearing types for industrial applications.

You can send BKZ Industry your bearing number, size, drawing, quantity, or application details, and their team will help you find the suitable bearing solution.
